M-Live B.Beat X 128 GB Wi-Fi Audio and Video Player

M-Live B.Beat X 128 GB Wi-Fi Audio and Video Player

M-Live B.Beat X 128 GB Wi-Fi plays up to 16 mono or 8 stereo tracks and provides eight audio outputs and two line inputs.

B.Beat X works independently under smartphone or tablet app control, or as an expansion for B.Beat and B.Beat PRO16 over LAN. Wireless connectivity is included in this 128 GB version.

The internal mixer routes individual tracks and manages the click, mixer return and headphone balance. Enabling the headphone output uses two audio channels, leaving six separate outputs available. 4 physical controls adjust the balance of the sources heard through the headphones.

Backing tracks, MIDI commands, video and images can be organized into playlists and shows made up of scenes. The video output displays synchronized visuals or lyrics, while PDF sheet music is sent to wirelessly connected devices running the Prompter app.

B.Beat Manager prepares projects, assigns outputs and sets track levels. The two-input, eight-output USB audio interface connects to a computer-based audio workstation for rehearsals and sound checks.

Main Features

• Combined with B.Beat, the system supports up to 32 mono or 16 stereo tracks and 14 audio outputs in total. The two players also provide separate outputs for video and lyrics.
• Combined with B.Beat PRO16, it manages 32 tracks across 24 audio outputs.
• The click track and metronome can be routed to a selected output and the headphones.
• Remote app control operates the player without a built-in screen.
• MIDI Clock synchronizes compatible stage equipment.
• LIVE mode limits accidental operations, and the synchronization system supports use with an automatic backup-system switcher.
• Song Service MTA backing tracks are supported as eight stereo tracks.
• An optional 2U rack panel integrates the unit into an equipment rack.

Technical Specifications

• Internal Storage: 128 GB
• Audio Tracks: Up to 16 mono or 8 stereo; up to 32 in expansion mode
• Internal Audio Format: PCM, 48 kHz, 24-bit
• USB Audio Interface: 2 inputs / 8 outputs, 44.1 / 48 kHz, 24-bit
• Audio Formats: WAV 44.1 / 48 / 96 kHz, 16 / 24-bit; MP3 CBR 64–320 kbps and VBR; OGG CBR 64–320 kbps; AAC; STEMS; MTA M-Live
• Video and Images: MP4, MOV, AVI; H.264, 1280 × 720 / 1920 × 1080; lyrics 1920 × 1080; JPG, PNG
• D/A Converter: 8 channels, 24-bit, 48 kHz, Sigma/Delta; typical S/N 112 dB
• A/D Converter: 2 channels, 24-bit, 48 kHz; typical S/N 107 dB
• Audio Inputs: 2 × 6.35 mm unbalanced mono; 10 kΩ; 18 dBu / 6 Vrms; typical THD+N -93 dB, SNR 107 dB
• Audio Outputs: 8 × 6.35 mm balanced mono; 10 dBu / 2.5 Vrms, balanced 20 dBu / 5 Vrms; typical THD+N -94 dB, SNR 112 dB
• Headphone Output: 6.35 mm stereo; 6 dBu / 1.5 Vrms; typical SNR 105 dB
• Network: Wi-Fi and RJ45 Ethernet 10/100/1000 Mbps
• MIDI: 5-pin DIN OUT; IN through an optional USB-MIDI cable
• Footswitch Connection: 6.35 mm, normally open or normally closed
• USB: 2 × USB 2.0 Type A; maximum combined current supply 500 mA
• Power: USB-C, 5.1 V DC, 3 A; 1700 mA; approximately six hours with a 10,000 mAh / 2.4 A power bank
• Project Software: B.Beat Manager: Windows 8.1 or later, macOS 10.15 Catalina or later
• SKU: MLI-BEAT X 128
• EAN: 0806812165339

What’s Included

• 1 × M-Live B.Beat X 128 GB Wi-Fi
• Power adapter
• RJ45 network cable

Who Is It For

For performances requiring more separate audio outputs or an expansion to an existing B.Beat system. Standalone control requires a smartphone or tablet running the control app. Allow two output channels for headphone monitoring when planning the signal routing.
