Allen & Heath ZED-6 Analogue Mixer

Allen & Heath ZED-6 Analog Mixer

Allen & Heath ZED-6 is a compact 6-input analog mixer designed for live sound, rehearsals, recording, streaming, podcasting and small sound systems.

The Allen & Heath ZED-6 is designed for applications where a small, reliable and straightforward analog mixer is required. It provides two mic / line channels, two stereo inputs and main XLR outputs, allowing microphones, instruments, keyboards, players, computers and other audio sources to be combined into one mix.

The ZED-6 features Allen & Heath GSPre microphone preamps, developed from the company’s GS-R24 studio console technology. They are designed for clean signal capture, low noise and high headroom. 48 V phantom power allows condenser microphones to be connected, while the Hi-Z instrument inputs make it possible to plug in a guitar or another high-impedance instrument directly without a separate DI box.

The mixer includes 2-band EQ, a low-cut filter and a headphone output for signal monitoring. The main XLR outputs are used to connect active speakers, an amplifier or another sound system. This is a compact analog mixer without an integrated effects processor, so it should not be confused with the Allen & Heath ZED-6FX version.

Main Features

• Compact 6-input analog mixer for live sound, rehearsals, recording and streaming
• Two mic / line channels for microphones, instruments and line-level audio sources
• Allen & Heath GSPre microphone preamps help maintain clean, low-noise signal capture
• 48 V phantom power for connecting condenser microphones
• Two Hi-Z instrument inputs for direct connection of guitar or another high-impedance instrument
• Two stereo inputs for keyboards, players, computers and other stereo audio sources
• 2-band EQ for quick channel tone adjustment
• Low-cut filter helps reduce unwanted low-frequency noise
• Main XLR outputs for active speakers, amplifiers or other sound systems
• Headphone output for convenient signal monitoring
• No integrated effects processor; this is not the ZED-6FX version

Technical Specifications

• Type: compact analog mixer
• Input count: 6
• Mic / line channels: 2
• Stereo inputs: 2
• Instrument inputs: 2 Hi-Z
• Microphone preamps: Allen & Heath GSPre
• EQ: 2-band EQ
• Low-cut filter: yes
• Phantom power: 48 V
• Main outputs: XLR
• Headphone output: yes
• Integrated effects processor: no
• Dimensions: 249 x 236.4 x 88.9 mm
• Weight: 1.36 kg

In the Box

• Allen & Heath ZED-6 mixer
• Power cable
• User guide

Who Is It For

The Allen & Heath ZED-6 is intended for musicians, vocalists, small bands, rehearsal rooms, content creators, podcasters, streaming setups and small sound systems. It is suitable for users who need a compact analog mixer with mic channels, stereo inputs, Hi-Z instrument inputs, main XLR outputs and straightforward control without an integrated effects processor.
