Klark Teknik DI 10A Active DI Box

Klark Teknik DI 10A Active DI Box

Klark Teknik DI 10A connects instrument and line-level sources to professional sound systems. Its active circuit and Midas transformer convert an unbalanced signal to a balanced output suitable for long cable runs.

The input impedance of more than 250 kΩ helps preserve the tone of passive guitars and basses. A three-position 0, -20, and -40 dB pad accommodates instrument and stronger line-level signals, while the THRU socket feeds a stage amplifier.

DI 10A can run from 18–48 V phantom power or a 9 V battery. Ground Lift helps address hum caused by ground loops, and the aluminium enclosure with rubber corners is designed for stage use.

Main Features

• Single-channel active DI box for instrument and line-level sources.
• Midas transformer provides galvanic isolation.
• 0, -20, and -40 dB input pad.
• THRU output for feeding an amplifier.
• Ground Lift helps reduce ground-loop noise.
• Powered by phantom power or a 9 V battery.
• Rugged aluminium enclosure with protective rubber corners.

Technical Specifications

• Inputs: 1 x XLR and 1 x 1/4-inch TS
• THRU: 1 x 1/4-inch TS
• Output: 1 x balanced XLR
• Input impedance: >250 kΩ
• Minimum load: 600 Ω
• Maximum input level: +10 / +30 / +50 dBu
• Frequency response: 10 Hz to 90 kHz, ±3 dB
• THD+N: <0.02%, 1 kHz, 0 dBu
• Noise: <-112 dBu
• Power: 18–48 V phantom power or 9 V 6LR61 battery
• Dimensions: 118 x 120 x 64 mm
• Weight: 0.56 kg

What’s Included

• 1 x Klark Teknik DI 10A active DI box

Who Is It For

Ideal for guitars, basses, keyboards, and other stage or studio equipment that needs an active DI solution with ample input headroom.
