Sound Generation: Analog synthesis
Programs: 99 programmes x 10 banks (5 factory banks, 5 user banks)
* Each program includes its own sequence pattern
* Able to set up to 13 favourite programmes can be registered

Synthesis Parameters:
Oscillator 1

• Frequency
• Pulse Width
• Sync (Off, On)

Oscillator 1 Waveshapes (continuously variable)

• Triangle
• Sawtooth
• Variable-width Pulse

Oscillator 2

• Frequency
• Fine
• Pulse Width
• Key Follow (Off, On)
• Low Frequency (Off, On)

Oscillator 2 Waveshapes (continuously variable)

• Triangle
• Sawtooth
• Variable-width Pulse

Oscillators

• Slop

Mixer

• Oscillator 1 Level
• Oscillator 2 Level
• Sub Level
• Noise Level

Low-pass Filter

• Cutoff
• Resonance
• Key Amount (Off, Half, Full)
• Velocity (Off, On)

High-pass Filter

• Cutoff
• Resonance
• Key Amount (Off, Half, Full)
• Velocity (Off, On)

Filter Envelope

• Low-pass Filter Amount
• High-pass Filter Amount
• Attack
• Decay
• Sustain
• Release

AMP Envelope

• Amount
• Velocity (Off, On)
• Attack
• Decay
• Sustain
• Release

Glide

• Rate
• Off, On
• Mode (Fixed Rate, Fixed Time, Fixed Rate A, Fixed Time A)

LFO

• Frequency
• Sync (Off, On)
• Initial Amount

LFO Shapes

• Triangle
• Reverse Sawtooth
• Sawtooth
• Square
• Random

LFO Destination

• Oscillator 1 Frequency
• Oscillator 2 Frequency
• Oscillator 1 and 2 Pulse Width
• Low-pass Filter Cutoff
• High-pass Filter Cutoff
• VCA

Modulation Source

• Filter Envelope
• Oscillator 2 Amount

Modulation Destination

• Oscillator 1 Frequency
• Oscillator 1 Shape
• Oscillator 1 Pulse Width
• Low-pass Filter Cutoff
• High-pass Filter Cutoff

Effects

FX 1 Types

• Bucket-brigade Delay
• Distortion
• Ring Modulation

FX 2 Types

• Chorus
• Low Resonance Phaser
• High Resonance Phaser
• Maestro Phaser

Parameters

• Each effect has 2 adjustable parameters

Sequencer

Step Length: Up to 64 steps
Parameters

• Key, Velocity, Slew (Off, On) for each step
• BPM (shared with arpeggiator)
• Time Divide (shared with arpeggiator)

Arpeggiator

Mode

• Up
• Down
• Up + Down
• Random
• Assign

Range

• 1 ~ 3 octaves

Parameters

• BPM (shared with sequencer)
• Time Divide (shared with sequencer)

Performance Controls

13-key touch keyboard
22 preset scales
9 octaves: C0 ~ C9 (use with Oscillator 1 and 2 frequency parameters)
Slider Parameters (multi assignable)
Oscillator 1 Frequency
Oscillator 2 Frequency
Low-pass Filter Amount
High-pass Filter Amount
LFO Amount
FX 1 Mix
FX 2 Mix
OLED Display
Able to access all parameters
MIDI Controllable Parameters

Aftertouch
Amount
Aftertouch Destination
Oscillator 1 Frequency
Oscillator 2 Frequency
Low-pass Filter Cutoff
High-pass Filter Cutoff
VCA
LFO Amount
Pitch Bend Range
Up to -/+ 12 semitones
Miscellaneous

Key Mode
Low
High
Last
Low Retrigger
High Retrigger
Last Retrigger
Alternative Tuning
17 preset tunings

Outputs:
1 AUDIO OUT L/R (1/4 inch TS Jacks)
1 PHONES (1/4 inch stereo phone Jack)
MIDI:
1 MIDI IN (5P DIN)
1 MIDI OUT/THRU (5P DIN)
USB: 1 USB B port
Others: 1 TRIGGER IN (1/4 inch TS jack)
Trigger Input
Able to connect a general foot switch or input audio signals
Able to set the operation from 4 types:
Pedal
Trigger
Gate
Trigger-Gate
